•   Door profiles

    Suitable for wooden doors.



      Traffic volume

    Medium to high



      Exterior usage

    IP56 (Extreme version)

    Up to 85% humidity.

    From -20°C to +70°C (external). From 0ºC to +50ºC (internal)



      Hardware compatibility and installation

    High retrofit. Easy installation without any wiring.



      Power supply

    Batteries from 80.000 to 105.000 cycles depending on the management system.

    Max. 3 years standby (depending on cycles per day)

    Three LR03 AAA 1,5V alkaline batteries.



      Multiauthentication

    Yes



      Status information

      Handle usage (only Wireless Online system)

      Thumb turn use: only in privacy model

      Door position: door sensor not included NO (normally open) connection

      Override cylinder (in combination with special mortise lock)



        Certifications

        CE (EMC, R&TTE), ROHS, REACH, WEE, EN14846 and EN12209



          RFID technologies

          13,56MHz Read & Write technologies. MIFARE Classic



            Compatible mobile solutions

            OPENOW

            TESA SMARTair (only with WIRELESS system).





              System management upgradability

            Compatible with the following SMARTair systems:

            • Offline/Update on card
            • Offline/Update on card + Openow

            -> Includes the Openow module

            • Wireless + Openow

            ->Includes the WIR + Openow module

            There is a firmware per system.

            SMARTair® Locks are scalable:

            • From Offline -> Wireless + Openow.

            -> Just adding the necessary Openow or WIR + Openow module and changing the firmware.
