CTSU100 Door Closer

The TESA CTSU100 door closer is the adjustable force model that is ideal for doors weighing up to 170 kg.

Main features:

• Makes it possible to control doors between 850 mm and 1100 mm wide.
• Two closing speed control valves and incorporates an opening brake mechanism.
• Reversible and suitable for single and double action doors.
• Continuous adjustment of force from EN2 to EN4.
• Internal hold-open system.
• The models with hold-open allow the door to be held open at between 150° and 180° (free swing zone).
• The model with no hold-open option (SR) has an opening stop at 150°.
• Internal opening brake.
• Supplied without spindle.
• Other types of spindle can also be selected on request.
• The decorative cover is ordered separately.

* We recommend downloading the technical data sheet below to see all the options.
